Name: 4-20ma Automotive Pressure Sensor Air Compressor Refrigeration 100bar Pressure Input
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA-H
Price: 21.00 USD
Availability: InStock

Evde > Ürünler > Compact Pressure Sensor >

4-20ma Automotive Pressure Sensor Air Compressor Refrigeration 100bar Pressure Input

electronic pressure sensor

precision pressure sensor

100bar Input Automotive Pressure Sensor

Menşe yeri:

HEFEI, ÇİN

Marka adı:

WNK

Sertifika:

CE, SGS, ISO9001

Model numarası:

WNK80MA-H

Bize Ulaşın

Teklif Et

4-20ma Automotive Pressure Sensor Air Compressor Refrigeration 100bar Pressure Input

Product Details

basınç girişi:

0-100bar

Kararlılık:

± %0,5 FS

tip:

Seramik Kapasitif Sensör

Başvuru:

Otomobil, Soğutma, HVAC

Sinyal çıkışı:

0,5-4,5VDC

Güç Girişi:

5VDC, 12V, 24V

Garanti:

12-18 Ay

IP Derecelendirmesi:

IP65 IP67

Vurgulamak:

electronic pressure sensor

precision pressure sensor

100bar Input Automotive Pressure Sensor

Payment & Shipping Terms

Min sipariş miktarı

5 parça

Fiyat

negotiable

Ambalaj bilgileri

Denize Uygun Ambalaj veya Havaya Uygun Ambalaj

Teslim süresi

7-10 iş günü

Ödeme koşulları

Banka havalesi, Western Union, MoneyGram

Yetenek temini

Ayda 5000 adet

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

En İyi Fiyatı Alın

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

En İyi Fiyatı Alın

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

En İyi Fiyatı Alın

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

En İyi Fiyatı Alın

Bize Ulaşın

Hemen İletişime Geçin

Product Description

4-20ma, 0.5-4.5V Compact Size Pressure Sensor Transducer For Automobile Air Compressor Refrigeration

Applications

- Automobile, Compressor and Refrigeration Industry

- Engineering machinery

- Pressure control and monitor

- Water treatment system

- Hydraulic and Pneumatics

- HAVC and BAS Control

- Pump, fitness equipment, household appliances

- Factory Automation

- Fluid Control and Instrumentation Systems

Our unique ceramic capacitive pressure sensor is made of stainless steel and well-known brand sensor The special transmitter converting circuit can adjust the zero value and the full range expediently. It also has the intrinsically safe certificate the explosion proof certificate and the CE certificate.

It features high quality high stability, small size, low weight, compact structure, low cost and volume production It is widely used to measure pressure such as occasion of compressor, Auto, air-condition etc.

Data Sheet

Pressure Type	Gauge Pressure , Absolute Pressure, Sealing Pressure
Pressure Range	-100Kpa - 60Mpa
Accuracy	0.2%, 0.5%, 1.0% FS
Power Supply	5VDC, 12-32VDC
Measuring Media	Gas, Steam, Liquid, Oil
Output
Analog	4-20mA, 0.5-4.5V, Other
Digital	I2C, SPI
Operation Condition and Temperature
Compensation Temperature	-40...75℃
Medium Temperature	-45 ... 85℃
Storage Temperature	-45 ... 85℃
Material and Protection
Ingress Protection	IP65, IP67
Housing Material	304SS, 316L
