Name: Stable Smart Pressure Transmitter Smart Pressure Transducer -100kPa - 70MPa Pressure Range
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK4S
Price: 45.00 USD
Availability: InStock

Evde > Ürünler > Smart Pressure Transmitter >

Stable Smart Pressure Transmitter Smart Pressure Transducer -100kPa - 70MPa Pressure Range

smart type pressure transmitter

digital pressure transmitter

Menşe yeri:

ANHUI, ÇİN

Marka adı:

WNK

Model numarası:

WNK4S

Bize Ulaşın

Teklif Et

Stable Smart Pressure Transmitter Smart Pressure Transducer -100kPa - 70MPa Pressure Range

Product Details

Ürün Adı:

WNK4S basınç vericisi

Basınç ölçümü:

Sıvı, gaz ve buhar

Basınç aralığı:

-100kpa ~ 70mpa

Kesinlik:

%0,2

Çıkış:

4~20mA, Modbus

Güç Kaynağı:

10,5-55VDC 10,5-30VDC

Muhafaza malzemesi:

Alüminyum14

Koruma Derecesi:

IP66/67

Eski:

ExiaII CT4/CT6, ExidIICT6

Ortam Sıcaklığı:

-40 ila 85°C,-40 ila 80°CLCD başlığı için

Vurgulamak:

smart type pressure transmitter

digital pressure transmitter

Payment & Shipping Terms

Min sipariş miktarı

1 Takım

Fiyat

negotiable

Ambalaj bilgileri

Koruma ile birlikte tek bir karton ambalajda her set

Teslim süresi

IP40

Ödeme koşulları

Banka havalesi, Western Union, MoneyGram

Yetenek temini

LCD başlığı için -45 ila 85°C,-40 ila 80°C

G1/4 Packard Capacitive Mini Pressure Transmitter For Liquid Gas Steam

En İyi Fiyatı Alın

Video

Brass Material High Accuracy Pressure Transmitter Liquid Level Transmitter 1/4 NPT

En İyi Fiyatı Alın

Video

Water Oil Air Smart Pressure Transmitter 4.75 - 5.25V DC Power Supply CE

En İyi Fiyatı Alın

Video

WNK83MA Customized Cable Outlet 0.5 - 4.5V DC Output Smart Pressure Sensor

En İyi Fiyatı Alın

Bize Ulaşın

Hemen İletişime Geçin

Product Description

Factory reset supportive stable pressure transmitter

WNK4S pressure transmitter is the cost-effective model of pressure transmitters provided by Hefei WNk Smart Technology Co., ltd. It transforms the physical signal of pressure , differential pressure and level etc into standard signal, by collecting cell sensor and digital processing circuit.

WNK4S series has the precision and signal uniformity by applying advanced specified integrated circuit digital technology.

Product Description

WNK4S pressure transmitters are suitable for:
1.Gauge,absolute and differential pressure measurement in gases,steam or liquids in areas of process control field.
2.Level,volume or mass mearsurement in liquids.

Product Name	4-20mA DC MODBUS Protocol Low Pressure Transmitter for HVAC
Pressure measurment	liquid, gas and steam
Pressure range	-100kPa~70MPa
Accuracy	0.2%
Output	4~20mA, Modbus
Power supply	10.5-55V DC 10.5-30V DC
Mechanical connection	G1/2, G1/4, 1/2NPT etc
Housing material	Aluminum14
Ingress Protection	IP66/67
Ex-proof	ExiaII CT4/CT6, ExidIICT6
Ambient temperature	-40 to 85ºC,-40 to 80ºCfor LCD header
Storage temperature	-45 to 85ºC,-40 to 80ºC for LCD header

Stable Smart Pressure Transmitter Smart Pressure Transducer -100kPa - 70MPa Pressure Range 5
