Name: Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK6T
Price: 403.00 USD
Availability: InStock

Evde > Ürünler > Smart Temperature Transmitter >

Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing

smart temperature sensor

industrial temperature sensor

Menşe yeri:

HEFEI, ÇİN

Marka adı:

WNK

Sertifika:

ISO

Model numarası:

WNK6T

Bize Ulaşın

Teklif Et

Profibus Rtd Smart Temperature Transmitter 4-20ma Output Aluminium Housing

Product Details

Ölçüm Aralığı:

0~1300°C, (Termokupl K)

Güç kaynağı aralığı:

9~45V (9~24V, Örn.)

Çıkış Sinyali:

4~20mA/Hart/Profibus PA

Malzeme:

Alüminyum gövde

Uzun süreli sürüklenme:

<0,1/yıl

Eski:

Exia II CT4

Medya:

Sıvı, gaz ve buhar

Vurgulamak:

smart temperature sensor

industrial temperature sensor

Payment & Shipping Terms

Min sipariş miktarı

1 Takım

Fiyat

negotiable

Ambalaj bilgileri

Standart İhracat Karton Ambalajı

Teslim süresi

5-7 iş günü

Ödeme koşulları

Banka havalesi, Western Union, MoneyGram

Yetenek temini

Ayda 5000 adet

44mm Diameter Hart RTD Liquid Gas Temperature Transmitter

En İyi Fiyatı Alın

Wireless Smart Temperature Transmitter For Timer Button Alarm Wake

En İyi Fiyatı Alın

CE Resolution 0.1C 18v 36V Temperature Humidity Sensor

En İyi Fiyatı Alın

Steam 24V PT100 Head Mounted Temperature Transmitter

En İyi Fiyatı Alın

Bize Ulaşın

Hemen İletişime Geçin

Product Description

Profibus Rtd Smart Temperature Transmitter 4-20ma Output

Description

WNK PROFIBUS-PA field bus WNK6T temperature transmitter is approved by PROFIBUS Nutzerorganisation e.V. For temperature sensor we can provide the thermal resister, thermocouple etc usually used in industry, we can also provide special sensor, including high temperature type,high pressure type,health type,with special material or with coating etc sensor. Customized sensor is also acceptable.

Features

1. High precision, digital precision up to :±0.01ºC
2. To reduce the overall cost of installation,maintenance and running
3. Install easily, more flexiable

4. LCD display, Menu-guided operation.

5, Self-diagnostics function

Data Sheet

Measuring media	liquid, gas and steam
Measuring range	-270~800 ºC (PT100 thermal resistor)
	0~1300ºC, (Thermocouple K)
Input	Thermocouple, RTD, MV, Resistive sensor
Power supply range	9~45V (9~24V, Ex)
Output signal	4~20mA/Hart/Profibus PA
Digital Accuracy	±0.01ºC, PT100 input
Internal cold end compensation error	<0.25ºC±0.1%/10ºC
Temperature drift	±0.05%/10ºCfull scale range
	0.1% between-10°C to 60°C
Effect of power supply on range	<0.005%/V full-scale range
Long term drift	<0.1/year
